USE
The RVA 600 variable speed system is a regulator controlled by a microprocessor which automatically varies the speed of single phase motors according to temperature.
This is recomended for controlling heating systems in order to keep the temperature constant in an area to be ventilated.
Supplied with temperature sensor :
- 1 sensor for RVA 6.
- 2 sensors for RVA 1200 (1 interior et 1 exterior).
The RVA 1200 AUX is a power amplification module for connection with a RVA 1200 or RVA 600.
It has a protection against over-currents, which can be set internally to protect the motor.
Domestic, industrial, agricultural uses.
Conditions of use :
- Ambient temperature: -10 to +40 C°.
- Speed variation from 40% to 100%.
- IP 54 protection box.
Power supply voltage 230 V single.
Protection fuse.
Luminous switch control.
