USE
Fan for ventilation and air extraction of small and medium-sized spaces (offices, bathrooms …).
Domestic, tertiary sector uses.
- Mounting on wall or ceiling, attached by 4 screws.
- AXIAL S : without time delay.
- AXIAL ST : time delay can be set between 5 and 20 mins.
Motor: 230 V single phase.
Case in ABS.
Propeller in ABS with 7 silent blades.
Surface area of the room to be ventilated / max. height 3 m./p> - Up to 4 m² AXIAL 100S : Fan model to install AXIAL 100ST
- UP to 6 m² AXIAL 125S : Fan model to install AXIAL 125ST
- Up to 11 m² AXIAL 150S : Fan model to install AXIAL 150ST
Download the operating instructions for axial fans
